P0336

Crankshaft position sensor, Input to control module missing or faulty







Fault symptoms
Engine will not start, running problems, misfiring

Conditions
The control module registers more then 20 signals from the camshaft position sensor without receiving a signal from the crankshaft position sensor during the same time.
or
The control module registers the wrong number of ribs on the slotted ring for 2 consecutive revolutions at more than 1000 rpm
