Checking the Preheating Element Control Module Input

Checking The Preheating Element Control Module Input












- Run the engine at idling speed until the coolant temperature exceeds 50 C (122 F).
- Connect test lamp 86 11 857 to B+ and pin 2 of the female connector.







- The test lamp should light.

Is the function correct?

NO -

YES -
