B2945

Sensor Ground, Open Circuit/Shorted To B+:

Fault symptom
Experienced temperature in cabin is too high or low when compared to set temperature.

Conditions
The following conditions apply:
- Measured every 40 ms.
- Voltage on pins 36, 38 or 39 > 0.4 V.
