B1215

Interior Lighting


















Fault symptoms
Interior lighting not working.

Condition
The output is overload protected and is cut if the load is too high. A DTC is generated it this occurs.
DTCs are not generated if the voltage is below 11V or during diagnostic communication.

Diagnostic help
Make sure the bulb is the correct rating.
If a lamp with too high a rating is fitted, diagnostic trouble code B1215 can be generated.
The overload protection is reset by turning the ignition OFF and then ON.

IMPORTANT
The DICE control module can be damaged if a bulb with incorrect rating is fitted.
