Grounding Points G30

Grounding Points: G2, G30:

The following components are connected to grounding point G3O behind the battery on the structural member:

11FL Lamp, dipped beam, LH
12FL Lamp, main beam, LH
13FL Lamp, parking light, left-hand
27FL Lamp, front direction indicator, LH Radiator fan
37 Radiator Fan
66FL Motor, headlamp wiper, left-hand
85FL Lamp, extra fog light, LH
119FL Lamp7 side reversing light, left-hand
134 Switch, brake, cruise control
166 Pressure switch, 3-stage, A/C
195 Washer fluid level switch
228b Filament monitor, front lamps
28OFL Motor, headlamp beam-length adjustment, left-hand
324 Relay, secondary air injection pump
325 Secondary air injection control valve
326 Motor, secondary air injection pump
547 Control module, ABS
