C1525

DTC C1515 or C1525

Circuit Description

These DTCs do not indicate a malfunction. The power steering control module outputs these DTCs when it determines that the rotation angle sensor value initialization and torque sensor zero point calibration have not been performed.

DTC Descriptors

This diagnostic procedure supports the following DTC:

* DTC C1515 Torque Sensor Zero Point Adjustment Undone
* DTC C1525 Rotation Angle Sensor Initialization Undone

Conditions for Running the DTC

This DTC shall run when key is inserted into key cylinder.

Conditions for Setting the DTC

C1515

The torque sensor zero point calibration has not been performed.

C1525

The rotation angle sensor value initialization has not been performed.

Action Taken When the DTC Sets

* Power assist stops.
* The P/S warning indicator illuminates.

Conditions for Clearing the DTC

The DTC will clear when conditions for setting the DTC have been repaired.
