C1514

DTC C1511-C1514 or C1517

Circuit Description

The torque sensor converts the rotation torque input from the steering wheel into electric signals and sends them to the power steering control module.

DTC Descriptor

This diagnostic procedure supports the following DTC:

* DTC C1511 Torque Sensor Circuit Malfunction
* DTC C1512 Torque Sensor Circuit Malfunction
* DTC C1513 Torque Sensor Circuit Malfunction
* DTC C1514 Torque Sensor Power Supply Abnormal
* DTC C1515 Torque Hold Abnormal

Conditions for Running the DTC

This DTC shall run when key is inserted into key cylinder.

Conditions for Setting the DTC

The power steering control module has detected a torque sensor malfunction.

Action Taken When the DTC Sets

* Power assist stops.
* The P/S warning indicator illuminates.

Conditions for Clearing the DTC

The DTC will clear when conditions for setting the DTC have been repaired.

Diagnostic Aids

If the steering column or power steering control module has been replaced, the rotation angle sensor initialization and torque sensor zero point calibration, must be performed. Refer to Steering Angle Sensor Initialization and Steering Shaft Torque Sensor Zero Point Calibration (Manual) (Steering Angle Sensor Initialization and Steering Shaft Torque Sensor Zero Point Calibration (Manual))Steering Angle Sensor Initialization and Steering Shaft Torque Sensor Zero Point Calibration (Scan Tool) (Steering Angle Sensor Initialization and Steering Shaft Torque Sensor Zero Point Calibration (Scan Tool)).
