B2501

DTC B2501

Circuit Description

When the ignition switch is turned to ON, the sensing and diagnostic module (SDM) will perform a turn-on test to diagnose critical malfunctions within the SDM itself.

Upon passing these tests, the ignition and deployment loop voltages are measured to ensure that these voltages are within the normal ranges. The SDM monitors the voltages at the driver low and the passenger low to detect shorts to ground or voltage in the deployment loops.

The SDM tests the voltage continuously from the warning lamp terminal.

DTC Descriptor

This diagnostic procedure supports the following DTC:

DTC B2501 Passenger Air Bag Disabled Indicator Circuit Malfunction

Conditions for Running the DTC

Ignition voltage is within the normal operating voltage range.

Conditions for Setting the DTC

The passenger ON indicator lamp does not operate depending on the status of passenger presence.

Action Taken When the DTC Sets

The SDM commands the AIR BAG indicator ON.

Conditions for Clearing the DTC

The condition responsible for setting the DTC no longer exists and the scan tool Clear DTCs function is used.
