B1451

DTC B1451

Circuit Description

When the ignition switch is turned to ON, the sensing and diagnostic module (SDM) will perform turn-on test to diagnose critical malfunctions within SDM itself.

The SDM continuously checks the disable switch position switch and circuit defect by letting the regular voltage flow through the disable switch circuit and verifying the current.

DTC Descriptor

This diagnostic procedure supports the following DTC:

DTC B1451 Manual Cut-off Switch Malfunction

Conditions for Running the DTC

Ignition voltage is within the normal operating voltage range.

Conditions for Setting the DTC

An open or short in wiring between SDM and disable switch.

Action Taken When the DTC Sets

The SDM commands the AIR BAG indicator ON.

Conditions for Clearing the DTC

The condition responsible for setting the DTC no longer exists and the scan tool Clear DTCs function is used.
