22. Engine Flywheel Clean and Inspect

1. Clean the flywheel in solvent.

CAUTION: Wear safety glasses in order to avoid eye damage.

2. Dry the flywheel with compressed air.





3. Inspect the flywheel for the following:
^ Damaged ring gear teeth.
^ Loose or improperly positioned ring gear.
The ring gear has an interference fit onto the flywheel and should be positioned completely against the flange of the flywheel.
^ A scored, grooved or damaged friction surface
