Antilock Brake System-Delco VI

REMOVAL PROCEDURE
1. Remove the I/P sound insulator panel.





2. Use pressure tabs in order to release the EBTCM (1) from the EBTCM bracket (2).
3. Remove the EBTCM electrical connectors.


INSTALLATION PROCEDURE
1. Install the EBTCM electrical connectors.





2. Slide the EBTCM (1) into the EBTCM bracket (2) until pressure tabs secure the EBTCM.
3. Install the I/P sound insulator panel.
