C1246

CIRCUIT DESCRIPTION
The normally closed outlet valves operate similarly to the inlet valves. When the EBCM/EBTCM grounds an outlet valve, however, the valve opens instead of closes.

The EBCM/EBTCM opens an outlet valve for short periods in order to reduce pressure at the left front wheel.

CONDITIONS FOR SETTING THE DTC
The DTC C1246 sets when the EBCM/EBTCM detects an open or short to ground in the left front outlet valve circuit.

ACTION TAKEN WITH THE DTC SETS
The following actions are taken when the DTC sets:
^ A malfunction DTC is stored
^ The ABS is disabled
^ The ANTILOCK indicator lamp is turned ON

CONDITIONS FOR CLEARING THE DTC
The DTC will clear under following conditions:
^ Conditions for the malfunction are no longer present. Use the scan tool clear DTCs function.
^ 100 ignition switch key cycles have passed without detecting any malfunctions

DIAGNOSTIC AIDS
Perform a thorough inspection of the wiring and the connectors.

Failure to inspect wiring carefully may result in a misdiagnosis. A misdiagnosis may result in replacing parts without repairing the malfunction.

Part 1 Of 2:

Part 2 Of 2:

DTC C1246 LF OUTLET VALVE CIRCUIT MALFUNCTION
