Fuel Pump Relay: Service and Repair

Description:

REMOVAL PROCEDURE

1. Turn the ignition OFF.

2. Remove the negative battery cable.

3. Remove the rear seat cushion.

4. Release the tabs from the rear relay electrical center (1) cover.

5. Remove the fuel pump relay from the rear relay electrical center.

INSTALLATION PROCEDURE

1. Install the fuel pump relay into the rear relay electrical center.

2. Install the rear relay electrical center (1) cover.

3. Turn the ignition OFF.

4. Install the negative battery cable.

5. Install the rear seat cushion.
