Checking M/T Oil

M/T OIL

Checking M/T Oil


OIL LEAKAGE AND OIL LEVEL

1.Make sure that oil is not leaking from transaxle or around it.





2.Remove filler plug (1) and check oil level at filler plug hole as shown.

CAUTION:
Do not start engine while checking oil level.
3.
Install a new gasket onto filler plug (1) and install it into transaxle. Tighten filler plug to specification. Transmission Assembly.

CAUTION:
Do not reuse gasket.
