Refilling

GEAR OIL

Refilling






1.Remove filler plug (1) and gasket from transaxle case.
2.Fill with new gear oil until oil level reaches the specified limit at filler plug mounting hole as shown in the figure.


3.After refilling gear oil, check the oil level. Inspection.
4.Set a gasket on filler plug and then install it to transaxle case.

CAUTION:
Never reuse gasket.
5.Tighten filler plug to the specified torque. Exploded View.
