Side Ventilator Grille

DUCT AND GRILLE


SIDE VENTILATOR GRILLE : Removal and Installation


REMOVAL
1. Remove instrument panel assembly. Removal And Installation.





2. Remove fixing screws (A), and then remove side ventilator grille from instrument panel assembly.

INSTALLATION
Install in the reverse order of removal.
