A/T Does Not Shift: D3-D2, When Selector Lever D3-D2

18. A/T Does Not Shift: D3 -> 2(2), When Selector Lever "D" -> "2" Position

SYMPTOM: A/T does not shift from D(3) to 2(2) when changing selector lever from "D" to "2" position.

1. CHECK PNP SWITCH CIRCUIT





With CONSULT-II
Does "TCM INPUT SIGNALS" in "DATA MONITOR" show damage to PNP switch circuit?
Without CONSULT-II
Does self-diagnosis show damage to PNP switch circuit?
Yes or No
Yes >> Check PNP switch circuit. Refer to "DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH".
No >> Go to "9. A/T Does Not Shift: D1 -> D2 Or Does Not Kickdown: D4 -> D2".
