Engine Does Not Return to Idle (Light Braking D4->D3)

15. Engine Speed Does Not Return To Idle (Light Braking D4 -> D3)

SYMPTOM:
- Engine speed does not smoothly return to idle when A/T shifts from D4 to D3.
- Vehicle does not decelerate by engine brake when turning A/T selector lever D to 3rd position.
- Vehicle does not decelerate by engine brake when shifting A/T from D to 2nd position.





1 of 7





2 of 7





3 of 7





4 of 7





5 of 7





6 of 7





7 of 7
