A/T Does Not Shift: D4- D3, With 3RD Position Switch Off
A/T Does Not Shift: D4- D3, With 3RD Position Switch Off
17. A/T Does Not Shift: D4 -> D3, When 3rd Position Switch ON -> OFF
SYMPTOM: A/T does not shift from D4 to D3 when changing selector lever from D to 3rd position.
