A/T Does Not Shift: D3->D4

11. A/T Does Not Shift: D3 -> D4

SYMPTOM:
- A/T does not shift from D3 to D4 at the specified speed.
- A/T must be warm before D3 to D4 shift will occur.





1 of 8





2 of 8





4 of 8





5 of 8





6 of 8





7 of 9





8 of 9





9 of 9
