Preliminary Check

A good understanding of the malfunction conditions can make troubleshooting faster and more accurate. In general, each customer feels differently about a malfunction. It is important to fully understand the symptoms or conditions for a customer complaint.

INFORMATION FROM CUSTOMER

WHAT ..............Vehicle model
WHEN ..............Date, Frequencies
WHERE ............Road conditions
HOW ...............Operating conditions, Symptoms

PRELIMINARY CHECK
Check that the following parts are in good order.

- Battery
- Fuse
- System component-to-harness connections
