With Manufacturer's Scan Tool

How to Erase DTC (With CONSULT-II)

NOTE: If the DTC is not for Apr related items, skip steps 2 through 4.

1. If the ignition switch stays "ON" after repair work, be sure to turn ignition switch "OFF" once. Wait at least 10 seconds and then turn it "ON" (engine stopped) again.
2. Turn CONSULT-II "ON" and touch "A/T".
3. Touch "SELF-DIAG RESULTS".
4. Touch "ERASE". [The DTC in the PCM (A/T control part of PCM) will be erased.] Then touch "BACK" twice.
5. Touch "ENGINE".
6. Touch "SELF-DIAG RESULTS".




7. Touch "ERASE". (The DTC in the PCM will be erased.)
- If DTCs are displayed for PCM (A/T control part and engine control part of PCM), they need to be erased individually from the PCM and TCM (Transmission control module).

The emission related diagnostic information in the PCM can be erased by selecting "ERASE" in the "SELF-DIAG RESULTS" mode with CONSULT-II.
