Symptom Related Diagnostic Procedures

Trouble Diagnoses for Interior Lamp Timer

















DIAGNOSTIC PROCEDURE 1
SYMPTOM: Interior lamp timer does not operate.










DIAGNOSTIC PROCEDURE 2
SYMPTOM: Interior lamp timer does not cancel properly.
