A/T Does Not Shift: When Selector Lever D->2 Position
A/T Does Not Shift: When Selector Lever D->2 Position
A/T Does Not Shift: D3 -> 22, When Selector Lever D -> 2 Position
SYMPTOM: A/T does not shift from D3 to 22 when changing selector lever from D to 2 position.
