9. A/T Does Not Shift: D1 -> D2 or Does Not Kickdown: D4 -> D2

#9:






SYMPTOM:
A/T does not shift from D1 to D2 at the specified speed.

A/T does not shift from D4 to D2 when depressing accelerator pedal fully at the specified speed.
