Basic Inspection
Basic Inspection
PRECAUTION:
Perform Basic Inspection without electrical or mechanical loads applied;
-
Headlamp switch is OFF,
-
Air conditioner switch is OFF,
-
Rear defogger switch is OFF,
-
Steering wheel is in the straight-ahead position, etc.
