18. LAN Signal 3 - Continued Reception After LAN Communication Starts

Inspection 18 - LAN Signal 3 - Continued Reception After LAN Communication Starts

DTC C1173


1. INSPECTION START





Check self-diagnosis results.

Self-diagnosis results
CONSULT-II display items
LAN SIGNAL 3

Do self-diagnosis results indicate anything other than the above?

YES >> Perform repair or replacement for the item indicated.
NO >> GO TO 2.

2. CHECK ENGINE SYSTEM
1. Perform self-diagnostic procedures for ECM.

Does "CAN-LAN CONVERTER COMM NG" appear on display?

YES >> Check ECM.
NO >> GO TO 3.

3. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
Check self-diagnosis results.

Self-diagnosis results
CONSULT-II display items
ABS-TCS C/U SIGNAL

Does "ABS-TCS C/U SIGNAL" appear on display?

YES >> Replace CLC. Repeat self-diagnosis for control unit.
NO >> If other items appear on display, repair or replace.
