Differential Side Shaft









DIFFERENTIAL SIDE SHAFT

1. Install oil seal and grease seal.

Tool number: KV38100200 (J26233).






2. Install extension tube retainer, rear axle bearing and rear axle shaft bearing collar on differential side shaft.
