A/T Does Not Shift: D1->D2 or Does Not Kickdown: D4->D2

A/T Does Not Shift: D1 -> D2 0r Does Not Kickdown: D4 -> D2





1 of 8





2 of 8





3 of 8





4 of 8





5 of 8





6 of 8





7 of 8





8 of 8

SYMPTOM: A/T does not shift from D1 to D2 at the specified speed. A/T does not shift from D4 to D2 when depressing accelerator pedal fully at the specified speed.
