Seals and Gaskets: Service and Repair

Rear Oil Seal Replacement
1. Remove transfer case from vehicle.
2. Remove rear oil seal.
- Do not remove oil seal unless it is to be replaced.





3. Install rear oil seal.
- Apply ATF before installing.
4. Reinstall any part removed.
