Nissan-Datsun Truck
>>
1999
>>
Frontier XE King Cab 4WD V6-3.3L (VG33E)
>>
Repair and Diagnosis
>>
Powertrain Management
>>
Transmission Control Systems
>>
Testing and Inspection
>>
Component Tests and General Diagnostics
>>
Diagnostic Procedures
>>
Diagnostic Procedure 19
Diagnostic Procedure 19
19.
A/T Does Not Shift: 2(2) -> 1(1), When Selector Lever 2 -> 1 Position
SYMPTOM: A/T does not shift from 2(2) to 1(1) when changing selector lever from 2 to 1 position.
