Home >> Nissan-Datsun Truck >> 1999 >> Frontier XE King Cab 4WD V6-3.3L (VG33E) >> Repair and Diagnosis >> Powertrain Management >> Transmission Control Systems >> Testing and Inspection >> Component Tests and General Diagnostics >> Diagnostic Procedures >> Diagnostic Procedure 13

Diagnostic Procedure 13

13. A/T Does Not Hold Lock-up Condition
SYMPTOM: AN does not hold lock-up condition for more than 30 seconds.
