Diagnostic Procedure 11
Diagnostic Procedure 11
11. A/T Does Not Shift: D3 -> D4
SYMPTOM:
-
A/T does not shift from D3 to D4 at the specified speed.
-
A/T must be warm before D3 to D4 shift will occur.
