Lancer Sportback L4-2.0L (4B11)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Backup Lamp
>>
Backup Light (Turbo)
Backup Light (Turbo)
BACKUP LIGHT [LANCER
(TURBO)]
