C-101 to C-142

DASH PANEL





C-101 (22) COMBINATION METER
C-102 (7) MODE SELECTION DAMPER CONTROL MOTOR AND POTENTIOMETER
C-104 (4) POWER TRANSISTOR
C-105 (7) AIR MIXING DAMPER CONTROL MOTOR AND POTENTIOMETER
C-106 (5) OUTSIDE/INSIDE AIR SELECTION DAMPERCONTROL MOTOR
C-108 (2-B) TWEETER (RH) [WITHOUT AUDIO AMPLIFIER]
C-109 (2) TWEETER (RH) [WITH AUDIO AMPLIFIER]
C-110 (4-Y) AIR BAG MODULE (SQUIB) (PASSENGERS SIDE)
C-111 (14) RADIO AND CD PLAYER OR RADIO, CD PLAYER AND CD CHANGER
C-112 (2) GLOVEBOX LIGHT
C-113 (18) AUDIO AMPLIFIER
C-114 (14) AUDIO AMPLIFIER
C-115 (2) BLOWER MOTOR
C-116 (14) RADIO, CD PLAYER ANDCDCHANGER
C-117 (10) RADIO, CD PLAYER ANDCDCHANGER [WITHOUT AUDIO AMPLIFIER]
C-119 (2) NO CONNECTION
C-120 (20-Y) SRS-ECU
C-121 (28-Y) SRS-ECU
C-122 (20-Y) SRS-ECU
C-123 (2) INTERIOR TEMPERATURE SENSOR [AUTOMATIC A/C]
C-125 (16-B) DATA LINKCONNECTOR
C-126 (2) AIR THERMO SENSOR
C-127 (6-L) RHEOSTAT
C-128 (6) FOG LIGHT SWITCH
C-129 (2-B) TWEETER (LH) [WITHOUT AUDIO AMPLIFIER]
C-130 (2) TWEETER (LH) [WITH AUDIO AMPLIFIER]
C-132 (1) GLASS ANTENNA
C-133 (10) TPMS RECEIVER
C-134 (22) RADIO,CD PLAYER AND CD CHANGER [WITHOUT AUDIO AMPLIFIER]
C-140 (4) AUX BOX
C-141 (6-B) AUX ADAPTER
C-142 (6-GR) ASC OFF SWITCH
