B-101 to B-120

ENGINE AND TRANSAXLE [2.4L ENGINE]





B-101 (3-GR) IGNITION COIL 1
B-102 (3-GR) IGNITION COIL 3
B-104 (2-B) ENGINE COOLANT TEMPERATURE SENSOR
B-105 (6-GR) EXHAUST GAS RECIRCULATION VALVE
B-106 (3-B) CAMSHAFT POSITION SENSOR
B-107 (3-GR) OUTPUT SHAFT SPEED SENSOR
B-108 (10-GR) A/TCONTROL SOLENOID VALVE ASSEMBLY
B-109 (3-B) INPUT SHAFT SPEED SENSOR
B-110 (10-B) TRANSMISSION RANGE SWITCH
B-112 (1) STARTER
B-113 (1-B) STARTER
B-115 (1) GENERATOR
B-116 (4-GR) GENERATOR
B-117 (3-GR) IGNITION COIL 4
B-118 (3-GR) IGNITION COIL 2
B-119 (3-GR) CRANKSHAFT POSITION SENSOR
B-120 (2-GR) KNOCK SENSOR
