C-201 to C-213

DASH PANEL





C-201 (10) Column switch
C-202 (5-R) Steering wheel audio remote control switch
C-203 (4-L) Cruise control switch
C-204 (5) Clock spring and steering sub wiring harness combination
C-205 (6) Clock spring
C-206 (1) Horn switch
C-207 (4-Y) Driver�s air bag module (squib)
C-208 (4-Y) Clock spring
C-209 (4-Y) Steering wheel voice control switch
C-210 (3) Paddle shift switch [Vehicles with sport mode]
C-211 (5) Steering wheel sensor
C-212 (6) Ignition switch
C-213 (12) Key reminder switch
