C-102 to C-143

DASH PANEL





C-102 (24) Radio and CD player [Vehicles with audio amplifier]
C-103 (24) Instrument panel wiring harness and multivision display wiring harness combination [Vehicles with MMCS]
C-104 (20) Radio and CD player
C-105 (20) Instrument panel wiring harness and multivision display wiring harness combination [Vehicles with MMCS]
C-106 (18) Radio and CD player
C-107 (18) Instrument panel wiring harness and multivision display wiring harness combination [Vehicles with MMCS]
C-108 (10) CAN box unit [Vehicles with MMCS]
C-109 (5) Outside/inside air selection damper control motor
C-110 (28) Hands free module
C-111 (5) Mode selection damper control motor
C-112 (4) Power transistor
C-113 (2) Blower motor
C-114 (12) Instrument panel wiring harness and front door wiring harness (RH) combination
C-115 (24-BR) Instrument panel wiring harness and front door wiring harness (RH) combination
C-116 (3) Inside transmission antenna assembly (front)
C-117 (1-B) Parking brake switch
C-118 (5) Air mixing damper control motor
C-119 (2) Fin thermo sensor
C-120 (12) A/C control panel
C-121 (6-B) Audio and video adapter
C-122 (24-Y) SRS-ECU
C-123 (6-B) Accelerator pedal position sensor
C-124 (24) Joint connector (CAN3)
C-125 (12) Instrument panel wiring harness and front door wiring harness (LH) combination
C-126 (24-BR) Instrument panel wiring harness and front door wiring harness (LH) combination
C-127 (16-BR) Instrument panel wiring harness and front wiring harness combination
C-128 (22) Instrument panel wiring harness and front wiring harness combination
C-129 (2) Instrument panel wiring harness and front wiring harness combination
C-130 (12) Instrument panel wiring harness and roof wiring harness combination
C-131 (6-GR) Headlight leveling switch [Vehicles with discharge type headlight]
C-132 (2) Clutch interlock switch [M/T]
C-134 (26) No connection
C-135 (6-B) Audio adapter
C-136 (12) Heater control panel [Vehicles without A/C]
C-137 (4-B) G and yaw rate sensor
C-138 (2) No connection
C-139 (20-B) No connection
C-140 (2-B) Electric power steering-ECU [Non-turbo (2.0L Engine)]
C-141 (4) Electric power steering-ECU [Non-turbo (2.0L Engine)]
C-142 (8) LIN cut off control unit [Vehicles with theft-alarm sensor]
C-143 (28) USB box
