Component Locations

GENERAL INFORMATION

COMPONENT LOCATION









NOTE:
The illustration above shows the front impact sensor (LH) and the side impact sensor (Front LH) and the side impact sensor (Rear LH). The position of the front impact sensor (RH) and the side impact sensor (Front RH) and the side impact sensor (Rear RH) is symmetrical to this.
