Home >> Mitsubishi >> 2007 >> Galant L4-2.4L (4G69) >> Repair and Diagnosis >> Transmission and Drivetrain >> Automatic Transmission/Transaxle >> Application and ID >> F4A4B >> Adjusting Plate, Snap Ring and Spacers >> Thrust Race (For Adjustment of Underdrive Sun Gear End Play)

Thrust Race (For Adjustment of Underdrive Sun Gear End Play)

Thrust race (For adjustment of underdrive sun gear end play):
