With Manufacturer's Scan Tool

ERASING DIAGNOSTIC TROUBLE CODES

WHEN USING SCAN TOOL MB991958
Required Special Tool:
^ MB991958: Scan Tool (MUT-III Sub Assembly)
^ MB991824: Vehicle Communication Interface (V.C.I.)
^ MB991827: MUT-III USB Cable
^ MB991911: MUT-III Main Harness B (Vehicles without CAN communication system)





CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the LOCK (OFF) position before connecting or disconnecting scan tool MB991958.

NOTE: If the battery voltage is low, diagnostic trouble codes will not be set. Check the battery if scan tool MB991958 does not display.

1. Connect scan tool MB991958 to the data link connector.
2. Turn the ignition switch to the ON position.
3. Select Interactive Diagnosis from the start-up screen.
4. Select System select.
5. Choose ABS from the CHASSIS tab.
6. Select MITSUBISHI.
7. Select Diagnostic Trouble Code.
8. If a DTC is set, it is shown.
9. Choose DTC erase to erase the DTC.
