How to Read Data List

HOW TO READ DATA LIST (MUT-III)
Required Special Tools:
^ MB991958: Scan Tool (MUT-III Sub Assembly)
^ MB991824: Vehicle Communication Interface (V.C.I.)
^ MB991827: MUT-III USB Cable
^ MB991911: MUT-III Main Harness B

CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the LOCK (OFF) position before connecting or disconnecting scan tool MB991958.





1. Connect scan tool MB991958 to the data link connector.
2. Turn the ignition switch to ON position.
3. Select Interactive Diagnosis from the start-up screen.
4. Select System select.
5. Choose ABS from the CHASSIS tab.
6. Select MITSUBISHI.
7. Select Data List.
8. Choose an appropriate item and select the OK button
