Windshield Wiper and Windshield Washer Switch Check [Eclipse Spyder]

WINDSHIELD WIPER AND WINDSHIELD WASHER SWITCH CHECK

Windshield Wiper And Windshield Washer Switch Check <Eclipse Spyder>:

Measure the resistance value at terminal numbers 27 and 28. The resistance value should rise smoothly from approximately less than two ohm ("FAST" position) to approximately one kiloohm ("SLOW" position).
