Windshield Wiper and Windshield Washer Switch Check

Windshield Wiper And Windshield Washer Switch Check (Eclipse Spyder):

Measure the resistance value at terminal numbers 27 and 28. The resistance value should rise smoothly from approximately less than 2 ohms ("FAST" position) to approximately 1 kohm ("SLOW" position).
