Front Suspension

GENERAL INFORMATION








The front suspension is of a multi-link construction with two lower arms which create the ideal virtual kingpin axis for the suspension system. In addition, by mounting the upper arm in a higher position than the tires, excellent steering stability and ride comfort are obtained.
