Without Antilock Brakes

REMOVAL AND INSTALLATION

Installation Service Point
>A< Brake Pipe Connection





Connect the pipes to the proportioning valve as shown in the illustration.
1. Proportioning valve - Rear brake (L.H.)
2. Proportioning valve - Rear brake (R.H.)
3. Proportioning valve - Front brake (R.H.)
4. Proportioning valve - Front brake (L.H.)
5. Proportioning valve - Master cylinder (secondary)
6. Proportioning valve - Master cylinder (primary)
