Clutch: Description and Operation

GENERAL INFORMATION
The clutch is a dry single-disc, diaphragm type; hydraulic pressure is used for the clutch control.
Clutch Operating Method: Hydraulic type.
Clutch Disc Type: Single dry disc type.
Clutch Disc Facing Diameter Outer Diameter X Inner Diameter: 225 x 150 mm (8.9 x 5.9 inch)
Clutch Cover Type: Diaphragm spring strap drive type.
Clutch Cover Setting Load: 6,174 N (1,388 lbs.)
Clutch Release Cylinder Inner Diameter: 20.64 mm (13/16 inch)
