Extension Housing: Service and Repair

DISASSEMBLY
Follow disassembly steps outlined in illustration.

ASSEMBLY
Assembly in reverse order as Disassembly.

NOTE: Assembly service points as follows:





A. Oil seal installation. (3)





B. Air bleeder installation. (1)
1. Apply sealant to the outer diameter of the air bleeder and install the air bleeder.
Specified sealant: 3M SUPER WEATHERSTRIP No. 8001 or equivalent.
