Windshield Wiper Motor Replace

Fig. 13 Front Wiper Motor & Transmission Replacement:

Remove front windshield wiper motor and transmission in numbered sequence, Fig. 23, noting the following:
1. Mark position of wiper arms before removal.
2. Reverse procedure to install.
