Sunroof - Service Procedures Revision

NO.: TSB-96-42A-005

DATE: March, 1996

MODEL: 1995 Eclipse

SUBJECT:
SUNROOF SERVICE PROCEDURES

SERVICE MANUAL REVISION

PURPOSE

The 1995 Eclipse service manual contains incomplete information on sunroof service procedures. This information is correctly printed in the 1996 Eclipse service manual.

The information in this Technical Service Bulletin replaces the affected service manual pages.

AFFECTED VEHICLES

1995 Eclipse models equipped with sunroof.

AFFECTED SERVICE MANUAL

1995 Eclipse Volume 1, pages 42-59 to 42-70





























SERVICE MANUAL CORRECTION

Place a copy of the service manual pages into section 42 of the 1995 Eclipse service manual. To refer to these new pages, write the TS8 revision number of this bulletin in the "TSB Revision" box at the bottom of service manual pages 42-59 to 42-70.
